Surface Mount Quartz Crystals

SURFACE MOUNT CRYSTALS

Key Features:

• Ultra-Miniature

• Frequencies from 10 kHz to 250 MHz

• Highest Shock Survivability in the Industry

• Tight Frequency Stability

• Low Acceleration Sensitivity

• High Reliability

• Excellent Long-Term Aging

CRYSTAL MODEL	Image	PACKAGE (mm)	FREQUENCY RANGE (Click for Data Sheet)
CX22/CX22HG Up to 75,000 g		1.2 x 1.0	30 MHz to 80 MHz
CX20		2.5 x 1.2	16 MHz to 100 MHz
CX18/CX18HG Up to 75,000 g		1.6 x 1.0	30 MHz to 100 MHz 32.768 kHz
CX17		4.8 x 3.0	10 MHz to 200 MHz
CX16		2.0 x 1.2	24 MHz to 100 MHz 32 kHz to 180 kHz
CX11		3.2 x 1.5	32 kHz to 240 kHz 14.7456 MHz to 250 MHz
CX11L		3.2 x 1.5	16 MHz to 250 MHz (Telemetry Crystal)
CX11LHG High Shock		3.2 x 1.5	16 MHz to 50 MHz
CX9HT High Temperature		4.1 x 1.5	32 kHz to 160 kHz 14 MHz to 250 MHz
CX4		5.0 x 1.8	30 kHz to 250 kHz 600 kHz to 1.4 MHz 14 MHz to 250 MHz
CX4HG High Shock		5.0 x 1.8	14 MHz to 50 MHz
CX4HT High Temperature		5.0 x 1.8	30 kHz to 250 kHz 600 kHz to 2.5 MHz 14 MHz to 250 MHz
CX1		8.0 x 3.6	10 kHz to 600 kHz 530 kHz to 2.1 MHz 6 MHz to 250 MHz
CX1HG High Shock		8.0 x 3.6	6 MHz to 250 MHz
CX1HT High Temperature		8.0 x 3.6	10 kHz to 600 kHz 530 kHz to 2.1 MHz 6 MHz to 250 MHz
SWCX1 (swept quartz)		8.0 x 3.6	6 MHz to 250 MHz
SWCX4 (swept quartz)		5.0 x 1.8	32.768 kHz 14 MHz to 100 MHz

For further information please call +1 714-639-7810 or e-mail sales@statek.com.         Link to  Tape & Reel Specifications
